| PARÇA ADI | PART NAME | MALZEME / MATERIAL |
|---|---|---|
| UZUN BURÇ | LONG BUSHING | PTFE |
| CONTA | GASKET | NBR / VITON / PTFE / EPDM / NR |
| MİL | STEM | AISI 416 |
| KISA BURÇ | SHORT BUSHING | PTFE |
| KLAPE | DISC | ALU-BRONZE / SS316 |
| PUL | WASHER | GR.33 |
| ORING | O-RING | NBR / VITON |
| KOL | LEVER | STEEL |
| CİVATA | BOLT | STEEL |
| SEGMAN | CIRCLIP | GR.33 |
| CODE IMPA | SIZE | FACE TO FACE (L) |
|---|---|---|
| 752400 | DN40 | 35 |
| 752401 | DN50 | 43 |
| 752402 | DN65 | 46 |
| 752403 | DN80 | 49 |
| 752404 | DN100 | 55 |
| 752405 | DN125 | 64 |
| 752406 | DN150 | 70 |
| 752407 | DN200 | 70 |
| 752408 | DN250 | 72 |
| 752409 | DN300 | 83 |
| 752421 | DN350 | 100 |
| 752422 | DN400 | 108 |
| 752423 | DN450 | 120 |
| 752433 | DN500 | 133 |
